Image Classification with TensorFlow

This repository provides a configurable image classification training pipeline using TensorFlow and Keras. It supports training from scratch or fine-tuning a pre-trained model, with customizable data augmentation, callbacks, and training parameters defined in a YAML configuration file.

---

Project Structure

• train.py — Main script to train the model.
• config.yaml — Centralized configuration file for training parameters.
• model/ — Contains model architecture definitions.
• utils/ — Utility functions, configuration loader, data augmentation previews, and custom callbacks.
• confusion_matrix.py — Script for model evaluation with custom F1-score metric and threshold optimization.

---

Setup Instructions

1. Open a terminal or command prompt.
2. Create a virtual environment using Anaconda:

   conda create -n name_env python=3.9

3. Activate the environment:

   conda activate name_env

4. Ensure pip is installed:

   conda install pip

5. Install project dependencies:

   pip install -r requirements.txt

---

Training

After setting up the environment and configuring config.yaml, run the training script:

python train.py

The model will be trained on the dataset specified in the configuration file, and the best model will be saved according to the selected evaluation metric.

---

Model Evaluation

The confusion_matrix.py script evaluates a trained binary classification model using a test set. It calculates a custom F1-score and can determine the optimal classification threshold. Optionally, it saves test images into structured folders for easier inspection.

Key Features

• Custom F1-score metric (TensorFlow/Keras-compatible)
• Automatic threshold optimization
• Two image-saving modes:
  • standard: saves images by true class
  • folder_split: saves images into out/0 and out/1 based on predictions
• Compatible with models trained using train.py

Usage

python confusion_matrix.py -m <path_to_model> [-s <threshold>] [--mode standard|folder_split]

Parameters

• -m, --model: Path to the saved model (required)
• -s, --threshold: Classification threshold (default: 0.5)
• --mode: Output mode: standard or folder_split
