CodeThreat Helm Chart

Kubernetes deployment chart for CodeThreat AppSec Platform.

Public Beta: This Helm chart is in public beta. Report issues or suggestions via GitHub.

Prerequisites

• Kubernetes 1.19+
• Helm 3.0+
• Access to CodeThreat container registry (registry.codethreat.com)
• CODETHREAT_TOKEN for registry authentication

Deployment Scope

Default Configuration: Optimized for POC and demo use. Suitable for evaluation and testing.

Production: Customize with enterprise configurations including high availability, security hardening, monitoring, and cloud optimizations. Contact your forward deployed engineer for production support.

LLM Configuration

Configure AI model settings before installation:

• config.defaultModel - Default AI model (default: gemini/gemini-2.5-flash-lite)
• config.hiveModelName - Primary Hive AI worker model (default: gemini/gemini-2.5-flash-lite)
• secrets.geminiApiKey - Google Gemini API key (required for default models)

Model Format: Use provider/model-name:

• gemini/gemini-2.5-flash-lite (default)
• openai/gpt-4
• anthropic/claude-3-opus
• groq/llama-3-70b

Uncomment and configure AI provider API keys in values.yaml as needed. Set values using --set flags or values.yaml.

Quick Start

1. Configure Registry Authentication

Set your CodeThreat registry token:

export CODETHREAT_TOKEN="your-token-here"

Note: Do not commit tokens to version control. Use --set flags or environment variables.

2. Generate Required Secrets

Generate secure random values:

export NEXTAUTH_SECRET=$(openssl rand -base64 32)
export ENCRYPTION_KEY=$(openssl rand -base64 32 | cut -c1-32)
export CREDENTIAL_ENCRYPTION_KEY=$(openssl rand -base64 32 | cut -c1-32)
export SHIFTQL_API_SECRET=$(openssl rand -base64 32)
export GITHUB_APP_WEBHOOK_SECRET=$(openssl rand -base64 32)
export BITBUCKET_SERVER_WEBHOOK_SECRET=$(openssl rand -base64 32)

3. Configure LLM API Key

Set your Gemini API key (or other AI provider key):

export GEMINI_API_KEY="your-gemini-api-key-here"

4. Install the Chart

You can configure secrets in two ways:

Option A: Using --set flags (recommended for secrets)

helm install codethreat ./helm/codethreat \
  --namespace codethreat \
  --create-namespace \
  --set imagePullSecrets.token="$CODETHREAT_TOKEN" \
  --set secrets.nextauthSecret="$NEXTAUTH_SECRET" \
  --set secrets.encryptionKey="$ENCRYPTION_KEY" \
  --set secrets.credentialEncryptionKey="$CREDENTIAL_ENCRYPTION_KEY" \
  --set secrets.shiftqlApiSecret="$SHIFTQL_API_SECRET" \
  --set secrets.githubAppWebhookSecret="$GITHUB_APP_WEBHOOK_SECRET" \
  --set secrets.geminiApiKey="$GEMINI_API_KEY" \
  --set config.bitbucketServerWebhookSecret="$BITBUCKET_SERVER_WEBHOOK_SECRET" \
  --set config.appUrl="https://codethreat.yourdomain.com" \
  --set config.nextauthUrl="https://codethreat.yourdomain.com" \
  --set config.nextPublicAppUrl="https://codethreat.yourdomain.com" \
  --set config.nextPublicApiUrl="https://codethreat.yourdomain.com" \
  --set ingress.enabled=true \
  --set ingress.host="codethreat.yourdomain.com"

Option B: Using values.yaml file

Create or edit values.yaml and set your secrets there, then install:

# Edit values.yaml with your secrets
helm install codethreat ./helm/codethreat \
  --namespace codethreat \
  --create-namespace \
  --values values.yaml \
  --set imagePullSecrets.token="$CODETHREAT_TOKEN"

Security: If using values.yaml:

• Do not commit to version control (add to .gitignore)
• Restrict file permissions (chmod 600 values.yaml)
• Store securely

Best practice: Use --set flags for secrets, values.yaml for non-sensitive configuration.

5. Verify Installation

kubectl get pods -n codethreat
kubectl get ingress -n codethreat

Configuration

Required Values

Value	Description	Generation
imagePullSecrets.token	CodeThreat registry authentication token	Provided by CodeThreat
secrets.nextauthSecret	NextAuth.js session encryption secret	openssl rand -base64 32
secrets.encryptionKey	Data encryption key (32 characters)	openssl rand -base64 32 | cut -c1-32
secrets.credentialEncryptionKey	Credential encryption key (32 characters)	openssl rand -base64 32 | cut -c1-32
secrets.shiftqlApiSecret	Shift-QL API authentication secret	openssl rand -base64 32
secrets.githubAppWebhookSecret	GitHub App webhook secret	openssl rand -base64 32
config.bitbucketServerWebhookSecret	Bitbucket Server webhook secret	openssl rand -base64 32
config.appUrl	Full application URL	Your domain
config.nextauthUrl	NextAuth.js callback URL	Should match appUrl
config.nextPublicAppUrl	Public application URL	Your domain
config.nextPublicApiUrl	Public API URL	Your domain

Optional Configuration

See values.yaml for complete configuration options including:

• Resource Management: CPU and memory limits/requests for all components
• Storage: Persistent volume sizes and storage classes
• Scaling: Replica counts for horizontally scalable workers (shift-ql, hive)
• Image Pull Policy: IfNotPresent (production) or Always (testing)
• AI Providers: OpenAI, Azure OpenAI, Ollama, Groq, Anthropic, Gemini, LiteLLM
• Email: SMTP, SendGrid, or Mailchimp configuration
• GitHub Integration: OAuth App and GitHub App credentials

Image Pull Authentication

The chart creates a Kubernetes Secret (codethreat-registry) for registry authentication. Provide the token during installation or upgrade:

# During installation
helm install codethreat ./helm/codethreat \
  --set imagePullSecrets.token="$CODETHREAT_TOKEN"

# During upgrade
helm upgrade codethreat ./helm/codethreat \
  --reuse-values \
  --set imagePullSecrets.token="$CODETHREAT_TOKEN"

Security: Do not set imagePullSecrets.token in values.yaml. Use --set flags with environment variables.

Accessing the Application

Port Forward (Testing)

kubectl port-forward -n codethreat svc/codethreat-appsec 3000:3000
# Access at: http://localhost:3000

Ingress (Production)

Enable ingress during installation or upgrade:

helm upgrade codethreat ./helm/codethreat \
  --namespace codethreat \
  --reuse-values \
  --set ingress.enabled=true \
  --set ingress.host=your-domain.com \
  --set ingress.tls.enabled=true

LoadBalancer Service

helm upgrade codethreat ./helm/codethreat \
  --namespace codethreat \
  --reuse-values \
  --set appsec.service.type=LoadBalancer

Security

Current Implementation

• Network policies restrict PostgreSQL access to chart components
• Secrets stored in Kubernetes Secrets
• Image pull authentication via Kubernetes Secrets
• Resource limits configured for all components

Production Recommendations

Default configuration is suitable for POC/demo. For production:

• Change default PostgreSQL password
• Enable TLS for ingress (ingress.tls.enabled=true)
• Use non-root containers (securityContext.runAsNonRoot: true)
• Enable Pod Security Standards
• Implement secret rotation
• Use external secret management (HashiCorp Vault, AWS Secrets Manager, GCP Secret Manager)

Contact your forward deployed engineer for production configuration guidance.

Secret Management

Do not commit secrets to version control. Use:

• --set flags during installation/upgrade
• External secret management systems
• Kubernetes Secrets

Architecture

Components:

• PostgreSQL - Embedded database (can be disabled for external DB)
• AppSec - Main Next.js web application
• Shift-QL - Security scanner workers (horizontally scalable)
• Hive - AI analysis workers (horizontally scalable)

Network Policies

• PostgreSQL access restricted to chart components
• Worker services (shift-ql, hive) can access external services

Storage

Persistent (survives pod restarts):

• PostgreSQL: Always persistent
• AppSec uploads: Persistent by default (set storageClass: "-" for ephemeral)
• Shift-QL cache/temp: Persistent by default (set storageClass: "-" for ephemeral)
• Hive cache: Persistent by default (set storageClass: "-" for ephemeral)

Ephemeral: Set storageClass: "-" in values.yaml to use emptyDir volumes

Scaling

Workers can be scaled horizontally:

helm upgrade codethreat ./helm/codethreat \
  --namespace codethreat \
  --reuse-values \
  --set shiftql.replicas=5 \
  --set hive.replicas=5

Database Migrations

Migrations run automatically via Helm pre-install/pre-upgrade hook:

1. Waits for PostgreSQL readiness
2. Ensures database exists
3. Runs Prisma migrations
4. Seeds database

Upgrading

helm upgrade codethreat ./helm/codethreat \
  --namespace codethreat \
  --reuse-values \
  --set imagePullSecrets.token="$CODETHREAT_TOKEN"

Uninstallation

helm uninstall codethreat --namespace codethreat

Warning: Uninstallation deletes all data unless PVCs are retained. Back up PostgreSQL first.

Troubleshooting

Check Pod Status

kubectl get pods -n codethreat
kubectl describe pod <pod-name> -n codethreat
kubectl logs <pod-name> -n codethreat

Check Image Pull Issues

kubectl describe pod <pod-name> -n codethreat | grep -A 5 "Events"
kubectl get secret codethreat-registry -n codethreat -o yaml

Check Migrations Job

kubectl get jobs -n codethreat
kubectl logs job/<release-name>-migrations -n codethreat

Database Access

kubectl exec -it <postgres-pod> -n codethreat -- psql -U codethreat -d codethreat

Support

For issues and questions:

• Email: info@codethreat.com
• Documentation: https://docs.codethreat.com
